ALCHAN MAT

HOMEPRODUCTAgricultural materialsALCHAN MAT

Description

It is specially processed with a special double-layered fiber structure to minimize
shrinkage and expansion, making it more resistant to abrasion and impact. One
side is black, preventing light from being transmitted and preventing weeds, and the
other side blocks light and infrared rays to help crop growth and maintain a pleasant
environment.



Features

  • Scattered light | A special white coating is used to block infrared rays and diffuse
    light to help crop growth and coloration
  • UV treatment | Resistant to ultraviolet rays and chemical resistance by sulfur resistant
    UV additive
  • Waterproof | Woven fabric is coated on both sides for perfect waterproofing
  • Weed prevention | Ultrafine carbon black pigment helps prevent weeds by blocking light
  • Versatile | Used as raised beds or drain receptacles with holes








Specification of TANTAN MAT

  • Width | 4.2m, 3.2m, 2.05m, and as per customer’s request
  • Width of Beds | 500mm, 600mm
  • Punching | Ø10mm 3 piercing, Ø15mm 3 piercing, Ø20mm 3 piercing, Ø20mm 1 piercing
  • Drainage | 700mm, 800mm
  • Color | Black / White, Black / Beige



Data Sheet

Number Item Test Method Direction TANTAN MAT 200 TANTAN MAT 165
1 Weight ASTM D 3776/2009 - 190 161.8
2 Tensile Strength ASTM D 5035(2011)
C.R.E. Stripping method: N/50mm		 MD 891.9 909.1
CD 783.0 696.0
3 Elongation ASTM D 5035-11(2011)
C.R.E. Strip method: %		 MD 21.8 23.0
CD 20.0 28.0
4 Tear Strength ASTM D 4704-
(2005)C.R.E / N		 MD 186.0 186.0
CD 142.2 128.0
5 Bursting Strength ASTM D 2136-02
(2012):APPEARANCE		 - NO CRACK NO CRACK
6 1000 hrs of
UV Exposure		 QUV 1,000 hrs ASTM D5035-2011
C.R.E, STRIP METHOD: retention %		 - 94.0 94.0
